GAF Energy
| OUTPUT | ||
| AC Output | Rated voltage | 220~240V / 100~120V |
| Rated power | 5000W / 4000W | |
| Peak power | 7000W | |
| Frequency | 50/60Hz | |
| DC 12V Output (Cigarette Lighter) | Rated voltage | 12V |
| Rated current | 10A | |
| USB-A output | 5V/3A; 9V/2A; 12V/1.5A; (18W Max); 5V/2A | |
| USB-C output | 5V/3A; 9V/3A; 12V/3A; 15V/3A; 20V/3A; (PD60W Max) | |
| Anderson output | 12V/30A | |
| INPUT | ||
| AC Charge Input |
200-240Vac 16A Max Slow 1250W/Fast 2500W 100-120Vac 16A Max Slow 900W/Fast 1800W |
|
| PV (Anderson) Input | 12~150Vdc MPPT: 18V-140V 15A Max 2100W Max | |
| BATTERY | ||
| Rated capacity | 5040Wh (48V 105Ah) | |
| Rated voltage / Lifecycles | 3500+ Cycles to 80% Original Capacity | |
| Battery cell type | LiFePO4 | |
| GENERAL | ||
| Waterproof | IP21 | |
| Working temperature | 0-40°C | |
| Size | 641.5*304.5*437.5mm | |
| Net weight | 50kg | |
| Certification | UL / CE / FCC / C-TICK / PSE / RoHS | |
| Warranty | 3 Years | |
